Debunking HDD myths

Rate this item
(0 votes)


1. Inside a hard drive assembly is a vacuum. Probably the most common delusion. I really don’t understand why people think this way, it’s not possible in principle, because magnetic heads float above the disk surface due to the air flow generated by revolving platters. So if there is no air, a hard drive will not be able to work according to the laws of physics. In reality, a hard drive assembly contains an ordinary, filter purified air with the same pressure as outside the assembly.


2. If a head stack assembly has failed and disk is clicking it is required to physically transfer magnetic platters to another working hard drive to recover data. This is the second most common delusion. I have no idea why in case of head stack assembly failure people for some reason think that platters have to be physically transferred. In practice, transferring platters to another hard drive assembly is a complicated and not always accomplishable procedure. Even professionals resort to this method only in the event of bearing failure. The processis complex because after platters are transferred you will have to make sure that they are aligned in the same way towards each other as they were in the old drive. In the majority of cases it is much easier to transplant head stack assembly from a working HDD to a faulty one, since HSA of most HDD models is firmly fixed to the axis and there is no need to align it.


3. There are special hard drive diagnostics and repair facilities where data can be recovered directly from damaged drive’s magnetic platters. Yes, such facilities do exist, although…mostly in the West and the cost of such recovery varies from a thousand to ten thousand dollars. And it is applicable only for some models of HDD and the recovery would only be partial. That is why it would be more appropriate to believe that there is no universal and all-embracing notion of such facility due to several issues. Firstly, all modern storage devices have different command systems and there is also such thing as translator. So, even if you read all disk sectors sequentially, you will still need to somehow salvage a logical structure of data from physical sectors. Secondly, the density of data storage on modern HDDs is such that reading information from HDD’s surface is possible only with its own heads and it is of no use if a platter is scratched because heads would crash immediately.


4. Overwritten data can be recovered using the disk’s residual magnetism. The way data is written on modern HDDs involves a complete magnetization of the surface area during data recording. That is why there is simply no residual magnetism.


5. State security agencies possess super equipment which is not available commercially. In reality, there are no wizards working for such authorities and they do not have a magic data recovery machine anyway. Moreover, the authorities quite often resort to commercial companies for data recovery.
